NZR DS meter mechanically calibrated 10(40)A 3x230

Mechanical three-phase current meter for direct connection DS 10(40)A, regenerated and calibrated. Single tariff, for meter cross mounting, for 4-wire networks, mechanical roller counter, accuracy class 2 in accordance with IEC 1036, mounting on meter cross according to DIN 43857, PTB approval. Voltage (U) 3x230/400V, current (I) 10(40)A, frequency (f) 50 Hertz, display mechanical counter 5/1 upon request for an additional charge mechanical counter 6/1, accuracy (active energy) 2 percent, internal consumption (Ue) less than 4 VA per phase for brand new meters, less than 4.5 VA per phase for regenerated meters, temperature range (Tb) --10 to +45 degrees C for regenerated meters, protection class (housing) IP 51, weight approx. 2.8 to 3.5 kg for regenerated meters, dimensions (W x H x D) 120 to 190 x 310 to 370 x 100 to 140 mm for regenerated meters, approved for billing purposes for 16 years from the calibration year
